The weft insertion mechanism of this high speed rapier loom has high precision, good rigidity, low acceleration of the movement of the gripper, no excessive yarn deformation during weft insertion, and conve- nient for weft clipping, weft cutting and weft yarn transferring. When changing the width, it is not required to adjust the time when the gripper is handed over at the center; the gripper band runs smoothly, does not require the gripper band guide hooks, avoids the interference of the guide hook on the warp yarn, and can adapt to the weaving of the high-density fabric or the delicate yarn requirements; electronic let-off and electronic take-up systems have a wide range of adaptability, while the control system provides a variety of ways of weft finding and weave compensation, can avoid start mark in most cases.
This loom can use wide range of yarns:
Cotton and synthetic fiber yarn: 500 te（x 1.2 Ne）- 5 te（x 120 Ne）
Slub and worsted: 680 te（x 1.5Nm）- 10 te（x 100 Nm）
Filament: 10 dte（x 9 den）- 1650 dte（1485 den）
The high speed rapier loom is highly efficient in producing a wide range of fabrics of all types:
Wool and worsted wool fabric
Light and medium cotton fabric
Fine twill cotton fabric and corduroy fabric
Rayon, synthetic fiber, silk fabric
Light and medium cotton woven or blended fabric
Light and medium industrial fabric
Fabric weight range: 40 grams per square meter to 450 grams per square meter
